Stiltz Home Lifts

Tech & Safety

• Lift Type Domestic Personal Home Lift that complies with the Machinery Directive 2006 / 42 / EC
• Height Limit Single floor. With a maximum of 4000mm of travel
• Electricity 230V socket - Plugs into a normal 13amp power socket
• Load Capacity Max. 170kg / 2 people.
• Drive Self-contained wire rope hoist system located in lift car roof space
• Dimensions 1940mm Internal lift car height / 790 x 720mm Lift car footprint / 1040 x 760mm Overall footprint
• Control Lift is controlled via the control panel and two remote controls. Additional remote controls are available
• Lift Car Door 1100mm hinged half-height door or full-height door options available. Full height LED light curtain will protect the entire door height.
• Illumination Contemporary ambient lighting with high-quality LED strips.
• Lift Height A minimum upper floor ceiling height of 2250mm is required
• Speed up to 150mm / sec
• Entrance Configuration Single door or Thru-car

Features and Benefits

• Tailored To Your Specific Taste The carpet, rail and colours in your Stiltz lift can all be changed to suit your home. Stilz also offers a range of different seats and handrails.
• Uninterrupted Power Supply This can be installed at an extra cost but will allow for numerous trips both up and down while the main power to the lift is out.
• Small Footprint The Duo+ footprint is 0.8m2 whilst the Trio+ footprint will accommodate a full-sized wheelchair and has a footprint of 1.44m2.
• Quiet Powered by a self-contained, electric drive motor which is completely hidden away in the lift car roof space. There is no noisy hydraulics with a Stiltz HomeLift.
• Fast Installation Standard installations can take as little as one day once the ceiling aperture has been created by a qualified builder.
• Power Consumption A Stiltz HomeLift plugs into a single, standard 13amp domestic power socket - just like any other domestic appliance. When running, it uses no more power than if you were to switch your toaster on.
• Unique Guide System It's what makes a Stiltz HomeLift so wonderfully versatile; our self-supporting structure of two parallel, vertical rails bear the entire load of the lift. No additional burden is placed on the structure of your home.
• Self Contained Drive System Our unique, self-contained drive system is cleverly concealed in a single space within the roof area o the lift car. No need for additional bulky plant rooms or other machinery.
• Fire Seal The Trio+ has undergone extensive fire seal testing and fully complied with BS5900:2012 Powered HomeLifts plus has full BS EN 81-41 accreditation.
• Automatic Door To make entry and exit more straightforward for wheelchair users or customers with limited mobility, the Trio+ has an automatic door available as an optional extra.
• Wide Entry Wheelchair users will find the wide entry and exit points of the new Trio+ particularly useful when manoeuvring their chair in confined spaces.
• Level Access For safety and comfort, the Trio+ comes with a gently-angled ramp to enable more convenient entry for wheelchair users and those unable to manage steps.

Dimensions

FAQs

What Happens If the Power Fails and I Am in My Stiltz HomeLift?

In the event of a power cut to the home, all Stiltz HomeLifts are equipped with a battery back up facility. This is included as standard and will allow anyone in the lift at the time of power failure to gently descend to the lower level of the home, exit the lift, and wait until the power comes back on.

Can I Stay in My Home Longer With a Stiltz HomeLift?

Yes, both the Stiltz Duo+ and Stiltz Trio+ are a great help to those with mobility problems, but they are also purchased by those who are able-bodied and looking to future proof their homes. This ensures you can have the peace of mind to continue to live a full life in the family home you love for many years to come.

Is a Stiltz HomeLift Suitable for Wheelchair Users?

Yes, the Stiltz Duo+ and Trio+ home lifts are ideal for homeowners with mobility issues as it allows them the freedom and independence to move between floors of the home with ease. Please note, however, that these through-floor lifts can only travel one floor, and that wheelchair users needing to access more than two storeys may benefit from a lift in our Aritco, Altura or PVE Vacuum range.

Am I Able to Receive a Disabled Facilities Grant for a Stiltz HomeLift?

You may be eligible for a Disabled Facilities Grant if you are disabled and need to make changes (including the installation of a domestic lift) to your home which would improve access to rooms and facilities. A Disabled Facilities Grant will not affect any benefit payments you receive.

How Safe Is the Stiltz HomeLift?

The Stiltz HomeLift has a safety sensor fitted above and below the lift car which detects obstructions and smoothly stop the car. The lift is also fitted with a full-height light curtain which acts as a sensor and ensures nothing crosses into or out of the lift as it travels. Stiltz home lift engineers are on call 24/7 in the event of a lift emergency.
